ABB MCCBs
ABB is a global leader in electrification and automation, supplying contactors, circuit breakers, switches, metering and control products for industrial and building installations. SSC Control is an authorised ABB partner, supplying the full range with genuine products, warranty and technical support across Gujarat and India.
Tmax XT1
Compact entry level moulded case breaker for residential and light commercial distribution.
- Frame: 160 A
- Breaking: 18 to 70 kA at 415V
- Poles: 3 / 4
- Trip: thermomagnetic
- Use: feeder and cable protection in small panels
Tmax XT2
High performance 160A frame supporting thermomagnetic and Ekip electronic releases.
- Frame: 160 A
- Breaking: 36 to 120 kA at 415V
- Poles: 3 / 4
- Trip: thermomagnetic or Ekip electronic
- Use: motor and feeder protection with metering
Tmax XT3
250A frame breaker for distribution boards needing higher continuous current.
- Frame: 250 A
- Breaking: 25 to 50 kA at 415V
- Poles: 3 / 4
- Trip: thermomagnetic
- Use: sub distribution and feeder protection
Tmax XT4
Premium 250A frame with full Ekip Touch electronic protection and precision metering.
- Frame: 250 A
- Breaking: 36 to 200 kA at 415V
- Poles: 3 / 4
- Trip: thermomagnetic or Ekip electronic
- Use: critical feeders, generators and motor circuits
Tmax XT5
Larger frame breaker covering 400 to 630A mains and feeder duties with Ekip releases.
- Frame: 400 to 630 A
- Breaking: 36 to 200 kA at 415V
- Poles: 3 / 4
- Trip: thermomagnetic or Ekip electronic
- Use: main incomers and large feeder protection
DSP
ABB SACE Formula DSP thermomagnetic moulded case range on P1, P2 and P3 frames for distribution and motor protection.
- Frame: 160 to 630 A
- Breaking: 18 / 25 / 36 / 50 kA
- Poles: 3 / 4
- Trip: thermomagnetic, fixed or adjustable
- Use: industrial and commercial power distribution
DSA
ABB SACE Formula DSA spanning A1, A2 and A3 frames with thermomagnetic or electronic releases for feeders and distribution boards.
- Frame: 125 to 630 A
- Breaking: 4.5 to 50 kA
- Poles: 3 / 4
- Trip: thermomagnetic or electronic
- Use: distribution boards, feeders and panel protection
Need an MCCB?
Our team can size the frame, breaking capacity and trip unit for your installation.
